| Base Material: |
Alloy: 6060, Temper: T5 |
| Finish: |
Clear anodised |
| Tread Width: |
78.5mm |
| Front Depth: |
10mm |
| Tread Thickness: |
4.8mm |
| Glow Strip: |
12mm photoluminescent strip |
| Insert Type: |
Solid silicon carbide – Heavy duty, external grade |
| Insert Width: |
50mm |
| Insert Colours: |
Black, yellow, light grey, white |
| Insert Slip Rating: |
P5/R12 |
| Code Compliance: |
AS1428.1-2021 |
| Features: |
Pre-drilled and countersunk for concealed fixings – once installed, insert covers all fixings |
| Application: |
Surface mounted on hard floor finishes |
| LRV: |
Black silicone carbide: Dry 4.50 / Wet 3.05 Yellow silicone carbide: Dry 37.64 / Wet 36.14 Light grey silicone carbide: Dry 33.22 / Wet 32.65 White silicone carbide: Dry 66.48 / Wet 65.56 |
